DCR IN CCRES
A Doppler Cloud Radar (denoted DCR) is an active remote sensing instrument operating in the millimetre wavelength range and providing vertical profiles of reflectivity and Doppler velocity of hydrometeors. The ACTRIS Cloud remote sensing network is composed of different types of DCRs:
-
Vertically pointing DCRs at 35 GHz
-
Scanning DCRs at 35 GHz
-
Vertically pointing DCRs at 94GHz
-
Scanning DCRs at 94GHz
DCR procedures and methods
TITLE |
VERSION |
LINK TO DOCUMENT |
| Absolute calibration method for FMCW Cloud Radar | 2019 | Absolute calibration method for FMCW Cloud Radar |
| Cloud Radar Standard Operating Procedures | 2021 | Standard Operating Procedures (SOPs). |
| Calibration Transfer Methodology for Cloud Radars Based on Ice Cloud Observations | 2023 | Calibration Transfer Methodology for Cloud Radars Based on Ice Cloud Observations |
| Horizontal Wind Plan Position Indicator (PPI) Measurement Conducted by RPG radars within the EarthCARE Cal/Val Framework | 2024 | PPI Wind RPG Radar |
| RPG FMCW Cloud Radar Triggered MBF's | 2024 | RPG FMCW Cloud Radar Triggered MBF's |
| RPG Cloud Radar chirp table | 2025 | RPG Cloud Radar chirp table |
